| iQ GRANIT – Technical Data | |
|---|---|
| Type of Floor Covering | Homogeneous single layered vinyl flooring, Type I |
| Standards | ISO 10581, EN 14041 |
| CE Certification | Yes |
| Classification | Commercial: 34, Industrial: 43 (ISO 10874) |
| Surface Treatment | iQ PUR |
| Total Thickness | 2.0 mm (ISO 24346) |
| Wear Layer Thickness | 2.0 mm (ISO 24340) |
| Total Weight | 2800 g/m² (ISO 23997) |
| Form of Delivery | Sheet (rolls), approx. 25 lm x 200 cm (ISO 24341) |
| Reaction to Fire | Class Bfl-s1, 28 kW/m², Pass (EN ISO 13501-1, 9239-1, 11925-2) |
| Marine Equipment | IMO FTPC Part 5 and 2, IMO Res. A653 |
| Total VOC Emissions | 10 μg/m³ after 28 days (ISO 16000-6, AgBB/DIBt, FloorScore) |
| Indoor Air Quality | Platinum Certified, SCS Certified |
| Clean Room Classification | ISO Class 4 (ISO 14644-1) |
| Bacteria Resistance | Does not favour growth (ISO 846 Part C) |
| Ease of Decontamination | Excellent (ISO 8690 – DIN 25415) |
| Chemical Resistance | Excellent (ISO 26987) |
| Slip Resistance | R9, μ ≥ 0.3 (DIN 51130, EN 13893, BS 7976-2) |
| Wet Room Approval | Watertight |
| Residual Indentation | Required ≤ 0.10 mm, Measured 0.02 mm (ISO 24343-1) |
| Castor Chair Suitability | Suitable (ISO 4918) |
| Static Electrical Charge | < 2 kV (EN 1815) |
| Underfloor Heating | Suitable (max. 27°C) |
| Light Fastness | Level 7 (EN ISO 105-B02) |
| Seam Strength | Average: ≥ 240 N/50mm, Individual: ≥ 180 N/50mm (EN 684) |
| Number of Colours | 10 |
